**Note: If sealed beam unit operates as a daytime running light (DRL), an additional harness will be required: SLDHH4
These LED sealed beam units provides substantially greater light output compared to traditional sealed beam units. Great for off-road industrial use. More economical than the DOT LED sealed beams, yet still offers a great driving beam pattern for low and high beams.
Features:
- More than 3 times brighter than original sealed beam lights!
- Retains true low and high beam patterns
- Reflector Lens designed to work with LED chips to increase light output, and maintain proper focal patterns, without overly altering the conventional sealed beam look
- Hard Coated Poly Carbonate Lens for increased durability
- Rugged Die-cast Aluminum Body
- Reduced radio interference with EMC circuitry
Bulb Cross References:
- 6052
- 6053
- 69822
- H5054
- H6052
- H6054
- H6054LL
- HP6054
Specifications:
- Body Construction Material: Aluminum Alloy
- Lens Material: Polycarbonate
- Input Voltage (Max): 32 V
- Input Voltage (Min): 9 V
- Color Temperature: 6000 K
- High Beam Raw Light Output: 3700 lm
- Low Beam Raw Light Output: 1800 lm
- High Beam Power: 35 W
- Low Beam Power: 20 W
- Total Power: 35 W
- IP Rating: IP67
- EMC (Reduction in radio noise): YES
- RoHS Compliant: YES
- Warranty: 1 Yrs
